PWS6A00T-P HITECH HMI Touch Screen 10.4inch 640x480 new in box
  • PWS6A00T-P HITECH HMI Touch Screen 10.4inch 640x480 new in box
  • PWS6A00T-P HITECH HMI Touch Screen 10.4inch 640x480 new in box

PWS6A00T-P HITECH HMI Touch Screen 10.4inch 640x480 new in box

£433.20


1,package included:

1pcs  PWS6A00T-P human machine interface HMI touch screennew in box;

1pcs programming cable(Only offer it free when you askfor after order. Not ship it default. The communication cable is not included,if you need, please contact us and inquiry it)

The software is free(we can send it by email if youcan’t download it by yourself)

2, Performance specification

Item

PWS6A00T-P

Display Type

TFT LCD

Display Color

64K colors

Display Size

10.4” (diagonal); display area is 213.2X160.4mm

Name of Pixels

640x480; Number of 8x8 characters displayable 80x60

Back Light

CCFT; Lifetime 50,000 hours @25 ºC

Touch Screen

Analog

Keypad

1“Menu” Key and user-defined Function keys(F1….F7)

Keypad Pressure& Lifetime

350±50gf operating force, Lifetime is over 1 million activations

Input Power

24VDC±15%; less than 30W

Flash ROM

8 M bytes

RAM

512 K bytes

CPU

32 bits RISC

Battery Backed Memory

512 K bytes

RTC

Yes

Data/Recipe

512K bytes

Data Storage(CF card)

Yes

COM1

9-pin female connector : RS232/RS485

COM2

25-pin female connector : RS232/RS422/RS485

COM3

9-pin female connector:RS422/RS485

USB Master

2 Ports

USB Device

1 Port

Multi-functional Port

Ethernet

Front Panel Seal

IP65

Ambient Temperature

0~50°C

Storage Temperature

-10~60°C

Ambient Humidity

10-90%RH(0~40° C),10-60%RH(41-50° C),non-condensing

Vibration Endurance

0.5mm displacement, 10-55Hz, 2 hours per X, Y, and Z-axis directions

Shock Endurance

10G, 11ms three times in each direction of X, Y, and Z axes

CE

EN61000-6-4,EN61000-6-2

External Dimensions(mm)

297.0(W) x 222.0(H) x 52.3(D)

Cut-out Dimensions (mm)

286.0 x 211.0

Weight

1.9 Kg

Colling

Natural cooling
