EA-035A-T Samkoon HMI Touch Screen 3.5 inch 320*240 new in box

Model: EA-035A-T
Shipping Weight: 1g
28 Units in Stock

£42.00
Sale: £34.86
Save: 17% off

Add to Cart:

1,package included:

EA-035A-T human machine interface HMI touch screen newin box;

programming cable(Only offer it free when you askfor after order. Not ship it default. The communication cable is not included,if you need, please contact us and inquiry it)

The software is SamDraw 5.0 free(we can send it by email if you can’tdownload it by yourself)

2, Performance specification

EA-035A-T Key Technical Parameters
Model	EA-035A-T
Display Size	3.5”(length : width=4:3)
Resolution	320 x 240
Brightness	350 cd/m²
Contrast	400 : 1
color	262, 144 color
Backlight	LED
Control panel	4-wire high-precision electric resistance touch screen
COM	1 X COM (RS232, RS422, RS485)
USB download port USB Device	YES
USB port USB Host	None
Ethernet port	None
SD card	None
Storage	DDR2 32MB
CPU	U32905U1DN
Supply power	DC: 24V (±15%),6W
Power consumption	3W
FCC compatibility	FCC, Class A
Pressure-proof test	500VDC / per minute
CE certification	EN55022 EN55024
Operation temperature	-10~65⁰
Operation humidity	10~90%RH( no condensation)
Shockproof degree	10-25Hz( X Y Z dimension 2G/30 minutes)
Protection Level	IP65( front panel)
Curst material	Engineering plastic ABS + PC
External size	868640.5 (mm)
Installed portiforium size	69x 69 (mm)
weight	About 0.2kg
Configuration software	SamDraw 5.0
