SK-070HE Samkoon 7 inch HMI Touch Screen 800*480 new in box replace SK-0

SK-070HE Samkoon 7 inch HMI Touch Screen 800*480 new in box replace SK-0

  • Model: SK-070HE
  • Shipping Weight: 1g
  • 28 Units in Stock

£68.40


Add to Cart:



1,package included:

1pcs  SK-070HE  humanmachine interface HMI touch screen new in box;

1pcs programming cable(Only offer it free when you askfor after order. Not ship it default. The communication cable is not included,if you need, please contact us and inquiry it)

The software SKTool is free(we can send it by email ifyou can’t download it by yourself)



The Sk-070BE screen was discontinued since April 1,2017 and replaced by the new SK-070HE model!

2, Performance specification

SK-070AE Key Technical Parameters

Model

SK-070HE

Display Size

7”(length : width=16:9)

Resolution

800 x480

Brightness

450 cd/m2

Contrast

400 : 1

color

262, 144 color

Backlight

LED

Control panel

4-wire high-precision electric resistance touch screen

COM

COM1 (RS232, RS422, RS485) and COM2 (RS232, RS422, RS485)

USB download port USB Device

YES

USB port USB Host

YES

Ethernet port

None

SD card

None

Storage

128M FLASH + 128M DDR2

CPU

32-bit 600MHz

Supply power

DC: 24V (±15%),10W

6

6W

FCC compatibility

FCC, Class A

Pressure-proof test

8KV

CE certification

EN55022 EN55024

Operation temperature

-10~650

Operation humidity

10~90%RH( no condensation)

Shockproof degree

10-25Hz( X Y Z dimension 2G/30 minutes)

Protection Level

IP65( front panel)

Curst material

Engineering plastic ABS + PC

External size

203x 145x 40 (mm)

Installed portiforium size

192x 138(mm)

weight

About 1.5kg

Configuration software

SKtool





Processing Time
