Product 922/2863
EC3 series is the most economical solutionfor sequential control and communication monitoring and can operateindependently, allowing the user to achieve stand-alone monitor, e.g.monitoring phototransistor coupler, proximity switch, optical sensor, indicatorand illumination switch. Through serial ports, EC3 is able to connect tocontrol devices such as PLC, frequency inverter and temperature controller,which can be said to be a programmable application solution that iscost-friendly and highly reliable
MPU points: 10/ 14 / 16 / 24 / 32 / 60
Max. I/O points: 60
Program capacity: 4k steps
COM ports: Built-in RS-232 and RS-485 ports (available in 16-60 point models); compatible with Modbus ASCII/RTU protocol
Built-in 4 points of high-speed counters
DVP10EC00R3
Delta
EC3 Series Standard PLC
100-240VAC
DI 6
DO 4 Relay
DVP10EC00T3
DO 4 Transistor
DVP14EC00R3
DI 8
DO 6 Relay
DVP14EC00T3
DO 6 Transistor
DVP16EC00R3
DO 8 Relay
DVP16EC00T3
DO 8 Transistor
DVP20EC00R3
DI 12
DVP20EC00T3
DVP24EC00R3
DO 12 Relay
DVP24EC00T3
DO 12 Transistor
DVP30EC00R3
DI 18
DVP30EC00T3
DVP32EC00R3
DI 16
DO 16 Relay
DVP32EC00T3
DO 16 Transistor
DVP40EC00R3
DI 24
DVP40EC00T3
DVP48EC00R3
DI 28
DO 20 Relay
DVP48EC00T3
DO 20 Transistor
DVP60EC00R3
DI 36
DO 24 Relay
DVP60EC00T3
DO 24 Transistor
